Cartridge Depleting System WKSK
The compact cartridge system WKSK provides the best conditions for the use of Euro-cartridges – even in highly automated production and assembly lines. It comes with an integrated pressure regulator and pressure display, as well as an optional pre-empty and empty signal, operates as an autarch, powerful system and guarantees a continuous medium supply without pressure deviations.
The closed pressure system pushes the bottom of the cartridge towards the outlet when medium is discharged and allows an overhead installation. Replacing cartridges is simple and does not need tools. In order to avoid air inclusions during a cartridge replacement, the cartridge system comes with an optimized design and an integrated safety function.
The module-based connection of several cartridges is an additional strong feature: it can be cascaded and will thereby guarantee an uninterrupted medium supply. You get even more flexibility with the exchangeable holder for plastic or aluminum cartridges. Above that, the cartridge system is compatible with all Walther MODULAR components and thus offers manifold options for the design and extension of individual dosing and application systems.
- compact, user-friendly, and process-secure emptying of plastic and aluminum Euro cartridges
- suitable for use in highly automated manufacturing and assembly systems
- uninterrupted media supply through cascading
- secured against air ingress into the fluid system
- inlet pressure (pneumatic): max. 10 [bar]
- operating temperature: 4 to 50 [°C]
- weight: 2,35 [kg]
- dimensions (l x w x h): 102 x 79 x 316 [mm]
- cartridge connection thread:
>> plastic: S15 x 2,5
>> aluminium: M15 x 1
- diameter cartridge:
>> plastic: Ø 46,2 [mm]
>> aluminium: Ø 46,8 [mm]
- length of cartridge: 215 - 216 [mm] (with or without flange)
- Walther Module length: 2 [TE]
